Replacement for Mahle filter

Model Number: PI 9111 DRG VST 10

Outer diameter : 47mm

Height : 248mm

inside diameter : 25.5mm

flow rate : 110l/min

fineness : 10µm

Get Quotation

Product Details

PI9111DRGVST10 Mahle filter element, the cleaner factory specializes in the production of replacement Mahle filter element, Mahle hydraulic oil filter element sells Mahle filter element, the original Mahle filter element, and the hydraulic filter element is used in the hydraulic system to filter out particles and rubber impurities in the system and ensure the cleanliness of the hydraulic system. The pressure difference of the hydraulic filter element is generally 0.35-0.4MPa, but some special filter elements are required to withstand the high pressure difference, and the maximum requirement is 32MPa, or even 42MPa equivalent system pressure. The maximum withstand temperature is 130 ℃.


Product features

1. Strength requirements, manufacturing integrity requirements, bearing differential pressure, bearing external installation forces, bearing alternating load of differential pressure

2. Requirements for smoothness of oil passage and flow resistance characteristics

3. Resistant to certain high temperature and compatible with working medium

4. The filter fiber cannot move and fall off

5. To carry more dirt

6. Normal use in high altitude and cold areas

7. Fatigue resistance, fatigue strength under alternating flow

8. The cleanliness of the filter element shall meet the standard



Product parameters


Model:

PI  9111 DRG VST 10

Place  of Origin:

Henan,  China

Brand  Name:

LVDA

Life  span:

2000-  4000h

Certificate:

ISO9001:2015

Quality:

100%  Tested

Outer  diameter

47mm

Height

248mm

inside  diameter

25.5mm

intake  diameter

25.5mm

end  cap below

verz.steel

material

Reinforced  wire mesh

fineness

10µm

flow  rate

110l/min

differential  pressure resistance

210  bar

sealing  material

NBR

sealing  arrangement

radial


Product application

1.Metallurgy

2. Petrochemical

3. Textiles, electronics and pharmaceuticals

4. Power Plant

5. Steel mills

6. Subway engineering

7. Chemical plant

8. Ships
