Product Details
The hydraulic filter is an important component in the hydraulic system to control the degree of oil contamination. Its function is to filter out solid particulate contaminants in the oil, so that the pollution degree of the oil is controlled within the limits that the critical hydraulic components can tolerate. To ensure the reliability of the hydraulic system and extend the life of components.Generally, it is considered that the hydraulic system with the filtering device is safe. Actually, this often causes a misunderstanding of the failure of the hydraulic system, and the influence of the quality of the filter itself on the system cannot be ignored.Proper selection of pollution control components in the hydraulic system for system target cleanliness directly increases system performance, extends component and fluid life and reduces maintenance, and avoids failure of more than 80% of hydraulic systems.
The hydraulic oil filter is mainly made of stainless steel woven mesh, sintered mesh, and iron mesh. Since it uses mainly fiberglass filter paper, chemical fiber filter paper, and wood pulp filter paper, it has high concentricity and high pressure. It has good straightness.
Its structure is made of single or multi-layer metal mesh and filter material. The number of layers and the mesh number of the mesh are determined according to different use conditions and use.
Product features
1.We use imported depthype filter material,tapered pore structure,gradient filter,can intercept granule furthest, to extend the service life.
2.We use hightech support materials.Hightech support materials can not only play the role of support filter, material and avoiding comprehensive deformation,but also protect the materials from being damaged during processing.
3.We also use the special spiral wrapping belts,so that filter layers can be connected firmly.Stationary pleated distance ensures the uniform flow when fluid penetrating the filter layer.Not only improving pressure drop,but also extending service life.
Product parameters
Model: | 319346 01.NL 250.40G.30.S1.P |
Place of Origin: | Henan, China |
Brand Name: | LVDA |
Life span: | 6000- 8000h |
Certificate: | ISO9001 |
Quality: | 100% Tested |
Working temperature: | -10~+100℃ |
Working pressure: | -21~210 bar |
PRODUCT NAME | Eaton 01.NL In-Line Filter Elements |
CATALOG NUMBER | 319346 |
PRODUCT LENGTH/DEPTH | 249.1 mm |
PRODUCT DIAMETER | 80 mm |
PRODUCT WEIGHT | .92 kg |
FILTER FINENESS | 40 G |
FILTER ELEMENT TYPE | In-line filter elements (DIN 24550-3) |
DELTA P RESISTANCE | 435 psi (30 Bar) |
FILTER MEDIA TYPE | Stainless steel wire mesh (G) |
SEALING MATERIAL | Nitrile |
NOMINAL SIZE | 250 |
Product application
1.Automotive
2.Heavy-duty on-highway transportation
3.Commercial trucks and buses
4.Agriculture
5.Construction
6.Industrial
7.Marine
8.Mining
9.Oil & Gas
10.Power Generation
