Replacement filter element is suitable for P551422 FUEL FILTER, WATER SEPARATOR CARTRIDGE
Replacement filter element is suitable for P551422 FUEL FILTER, WATER SEPARATOR CARTRIDGE
Replacement filter element is suitable for P551422 FUEL FILTER, WATER SEPARATOR CARTRIDGE
Replacement filter element is suitable for P551422 FUEL FILTER, WATER SEPARATOR CARTRIDGE

Replacement filter element is suitable for P551422 FUEL FILTER, WATER SEPARATOR CARTRIDGE

Replacement for Donaldson filters

Model Number: P551422

Outer Diameter : 80 mm (3.15 inch)

Length : 196.3 mm (7.73 inch)

Efficiency 99% : 3 micron

Emulsified H2O Efficiency : 95.00 Percent

Type : Water Separator

Get Quotation

Product Details

In order for the mixture of fuel and air to explode well in the engine, there must be no impurities mixed in the fuel. Therefore, impurities contained in fuel must be removed, and this role is the fuel filter. However, one of the parts that is difficult for drivers to find in the engine room is also a fuel filter. In particular, depending on the type of vehicle, the fuel filter can be seen only by lifting the car with a lift, and most gasoline vehicles released these days have fuel filters inserted into the fuel tank, making it difficult for drivers to check. In the book, let's look at diesel (common rail) fuel filters as a standard.

In most diesel cars, fuel filters are installed in the engine room, and the replacement cycle is shorter than gasoline due to the ultra-high pressure injection method, but the quality of oil fuel has improved recently, and the life of fuel filters is also increasing. In addition, the fuel filter of the diesel vehicle is equipped with a heater device to prevent fuel from freezing even in winter, and a moisture sensor is integrally mounted.


When replacing the fuel filter, the driver must decide whether to replace it with an assembly or only the filter element. The cost varies by three times depending on this selection, and it is generally recommended that the assembly be replaced once for two replacements of the element. The average replacement time for fuel filters is 60,000 km for gasoline and 30,000 km for diesel, and it is preferable to refer them to the repair shop because it is difficult for the driver to replace them himself. Even when requesting a repair shop, if only the filter element is replaced, the difficulty of the work is high, so you will pay more for the technology, but the overall cost can be saved.


Product features

1. Versatile – no keys necessary for installation; universal interface allows one part to fit multiple applications.


2. Integrated hose barb allows attaching a hose to drain water to a container.


3. Fully compatible with OEM accessories such as water collection bowls, drain valves, and water-in-fuel (WIF) sensors.


Product parameters


Model:

P551422

Place  of Origin:

Henan,  China

Brand  Name:

LVDA

Life  span:

2000-  4000h

Certificate:

ISO9001:2015

Quality:

100%  Tested

Outer  Diameter

80  mm (3.15 inch)

Length

196.3  mm (7.73 inch)

Efficiency  99%

3  micron

Efficiency  Test Std

SAE  J1985

Emulsified  H2O Efficiency

95.00  Percent

Type

Water  Separator

Style

Cartridge

Media  Type

Composite

Notes

Not  for Marine Applications


Product application

1.Automotive

2.Electronics

3.Food & Beverages

4.Chemical

5.Petrochemical

6.Plastics

7.Paint

8.General Industrial application
