Substitute AtlasCopco UD425+ Air Compressor Filter with Coalescing Technology

Substitute AtlasCopco UD425+ Air Compressor Filter with Coalescing Technology

Replacement for Atlas Copco filter

Model Number: UD425+

Dimensions (L x W x H) : 210mm x 128mm x 791mm

Weight : 11.0 KG

Particle removal : 0.01 microns

Suitable for flows : 425 l/s

Connections : Inlet / Outlet: 3" Female

Product Details

Atlas Copco’s UD+ filters efficiently reduce all types of contamination in your compressed air stream to protect your investment, equipment and processes. Thanks to its unique glass fiber filter media package, the UD+ offers a two-in-one filter technology, combining two filtration processes in one product. The UD+ offers the same reliability and high air purity as traditional filter packages (with two filters), but reduces pressure drops with 40% and saves space.

Product features

1.Positively affect the quality of your compressed air and therefore the protection of downstream equipment.

2.Reduce the overall cost of the system by reducing the pressure drop across the filter.

3.Protect your air dryer and reduce the overall cost of maintenance.

4.Increase productivity and profitability by reducing overall operational costs.

Product parameters

Model:	UD425+
Place of Origin:	Henan, China
Brand Name:	LVDA
Life span:	6000- 8000h
Certificate:	ISO9001
Quality:	100% Tested
Working temperature:	-10~+100℃
Working pressure:	-21~210 bar
Suitable for flows of	425 l/s (901 cfm) @ 7 bar.g (102 psig)
Particle removal to	0.01 microns (ISO 8573-1 Class 1)
Liquid oil removal to	0.0009 mg/m3 (ISO 8573-1 Class 2)
Connections	Inlet / Outlet: 3" Female
Dimensions (L x W x H)	210mm x 128mm x 791mm
Weight	11.0 KG
