Compressed air leaving your air compressor may have particulate, oil mist or other contaminants present. Even air downstream of compressed air dryers or air receivers may encounter particulate or develop condensate within piping before the point of use. Different use requirements and different contaminants require different filters. It is recommended that all compressed air systems have appropriate filtration installed before point of use. Atlas Copco has developed specific filter grades to address the various contaminants found in compressed air systems.
Air compressed filter element can filter out contaminants such as rust, pipe scale,compressor lube oil, and water from compressed gases. Media choices range is high-temperature coalescers through bulk liquid removal, particulate-removal, and oil vapor (odor) removal filter elements.
Air compressed filter element offers a range of filtration and separation solutions that are designed to meet the needs of global clients through a dedicated focus on key market sectors. If you are interested in our products. Welcome to contact us anytime. We are online 24 hours a day.
Grade DD - General Purpose Protection Particle removal down to 1 micron including coalesced liquid water and oil, providing a maximum remaining oil aerosol content of 0.6 mg/m3 (<0.5 ppm) @ 21°C.
Grade PD - High Efficiency Oil Removal Filtration
Particle removal down to 0.01 micron including water and oil aerosols, providing a maximum remaining oil aerosol content of 0.01 mg/m3 (<0.01 ppm) @ 21°C. (Precede with Grade GP filter).
Grade QD - Activated Carbon Filtration
Oil vapour and hydrocarbon odour removal, giving a maximum remaining oil content of <0.003 mg/m3 (<0.003 ppm) (excluding methane) @ 21°C. (Precede Grade AC with Grade HE filter).
Grade DDp - General Purpose Dust Filtration
Dust particle removal down to 1 micron.
Product features
1. Ideal filtration and discharge effect of oil mist, wet dust and water
-The efficient glass fiber Nautilus Nautilus technology can carry out efficient filtration and ensure the loss of low pressure drop at the same time;
2. Specially designed drainage technology
The 3D structure design of the end cover at the bottom of the filter element ensures the efficient separation and discharge of oil-water impurities, and prevents the separated oil-water impurities from entering the air flow again;
3. Reduce operation cost
-Reasonable design and filtration technology ensure low pressure drop loss;
4. Convenient maintenance
-The shell with rib design is convenient for disassembly;
-The design and replacement of push in filter element and integrated drain valve are simple;
-The maintenance indicator shows the use status of the filter;
Product parameters
Model: | 2901200408 |
Place of Origin: | Henan, China |
Brand Name: | LVDA |
Life span: | 6000- 8000h |
Certificate: | TS16949/ISO9001:2015 |
Efficiency: | 99.99% |
Quality: | 100% Tested |
Material: | Glassfiber, Stainless steel, Filter paper |
Type: | Air Filter,In-line Filter |
Filtering precision: | 0.01~3 μm |
Thread Size | Standard size |
Body Height (H-0) |
420 mm |
Height-1 (H-1) |
15 mm |
Total Height (H-TOTAL) |
435 mm |
Product Net Weight (WEIGHT) |
0.85 Kg |
Inner Diameter 1 (Ø 1 IN) |
58 mm |
Outer Diameter (Ø OUT) |
102 mm |
Stat. HS-Code |
84149000 |
Product application
1. Metallurgy: It is used for the filtration of the hydraulic system of rolling mills and continuous casting machines and the filtration of various lubricating equipment.
2. Petrochemical: used for separation and recovery of finished products and intermediate products in the process of oil refining and chemical production, liquid purification, purification of magnetic tapes, optical discs and photographic films in manufacturing, oil field well injection water and natural gas for particle removal and filtration.
3. Textiles, electronics and pharmaceuticals
4. Power Plant
5. Steel mills
6. Subway engineering
7. Chemical plant
8. Ships
