Product Details
When the compressed gas to be processed enters the filter, the flow rate slows down, and the droplets of large particles fall down under the action of gravity.
When the smaller diameter liquid droplets and solid particles pass through the filter element with the gas, they are captured by the filter material due to inertial collision and gradually condensed into larger droplets to stay. Smaller solid and droplet particles do not change direction with the airflow, but do Brownian motion. Once they approach the filter material, they will be adsorbed on the filter material under the influence of the electrostatic attraction of the glass fiber.
The filtered water collects at the bottom of the filter and is discharged through the drain. In order to protect the environment, it is recommended that the discharged oil and water be collected in a special container and not directly discharged into a public sewage pipe.
Product features
1.Maximum oil aerosol, wet dust and water droplet filtration and drainage
High- efficient glass fiber and foam media.
2.Significant energy savings & limited system operating costs
Optimal design and filter media allow low pressure losses.
3.High reliability
High- performance stainless steel cores, double O-rings,epoxy sealed caps, and anti-corrosive coated filter housing.
4.Easy maintenance
External ribs on the threaded housing,or a rotating bottom cover for the welded housings,and push-on elements.
5.Monitoring of energy use
Differential pressure indication (indicator for sizes 10-35 I/s,gauge for sizes 50 -8000 I/s) loptional for standard range).
Product parameters
Filtration Type | High Efficiency Filtration |
Maximum Oil Carryover | 0.01 ppm Oil Removal |
Micron Rating | 0.01 Micron |
Product Type | Aftermarket/Replacement |
Grade | Filtration rating | Oil content |
DD | 1µ | 1ppm |
DDP | 1µ | dust removal |
PD | 0.01µ | 0.01ppm |
QD | 0.01µ | 0.003ppm (activated carbon) |
Place of Origin: |
Henan, China |
Brand Name: |
LVDA |
Type: |
Air Filter,precision filter element |
Application: |
Atlas Copco Air Compressor |
Certificate: |
ISO9001:2015 |
Material: |
fiberglass imported from HV&Ahlstrom company.wire mesh etc |
Pressure: |
High Pressure |
Filtration Efficiency: |
99.99% |
Life cycle: |
> 6000 hours |
Product application
1.Hotels,
2.Garment Shops,
3.Building Material Shops,
4.Manufacturing Plant,
5.Machinery Repair Shops,
6.Food & Beverage Factory,
7.Farms, Restaurant,
8.Home Use,
9.Retail,
10.Food Shop,
11.Printing Shops,
12.Construction works,
13.Energy & Mining,
14.Food & Beverage Shops,
15.Advertising Company
