Coalescing (Pre-Filter) Filters Often called the pre-filter since itis placed on the air line just prior to the air dryer, a coalescingfilter removes oil, particles and moisture before it can come incontact with the desiccant in the dryer and ruin it.
DD(+)/PD(+) SERIES
High performance oil coalescing filters
DD(+) and PD(+) filters efficiently reduce oil aerosol,wet dust and water drops in your compressed airstream. These could come from the lubrication of the compressor element, the intake air, and the compressor installation itself. These innovative filtration solutions are engineered to cost-effectively provide the best air purity and meet today's increasing quality demands.
TEST STANDARD:
Our filter elements are tested according to ISO 2943
Compatibility with suction fluids ISO 3968
Flow characteristics ISO/DIS 3724
Flow fatigue characteristics ISO/DIS 4572
Filter performance test (Multi-pass test) ISO 2942
Proof of integrity and quality (Bubble point test) ISO 3723
Verifiion of the end cap stress ISO 2941
Collapse / burst pressure verifiion
Product features
1.Maximum oil aerosol, wet dust and water droplet filtration and drainage
High- efficient glass fiber and foam media.
2.Significant energy savings & limited system operating costs
Optimal design and filter media allow low pressure losses.
3.High reliability
High- performance stainless steel cores, double O-rings,epoxy sealed caps, and anti-corrosive coated filter housing.
4.Easy maintenance
External ribs on the threaded housing,or a rotating bottom cover for the welded housings,and push-on elements.
5.Monitoring of energy use
Differential pressure indication (indicator for sizes 10-35 I/s,gauge for sizes 50 -8000 I/s) loptional for standard range).
Product parameters
Grade | Filtration rating | Oil content |
DD | 1µ | 1ppm |
DDP | 1µ | dust removal |
PD | 0.01µ | 0.01ppm |
QD | 0.01µ | 0.003ppm (activated carbon) |
Place of Origin: |
Henan, China |
Brand Name: |
LVDA |
Type: |
Air Filter,precision filter element |
Application: |
Atlas Copco Air Compressor |
Certificate: |
ISO9001:2015 |
Material: |
fiberglass imported from HV&Ahlstrom company.wire mesh etc |
Service life: |
> 6000 hours |
Pressure: |
High Pressure |
Filtration Efficiency: |
99.99% |
Life cycle: |
> 6000 hours |
FILTER SIZE
DD/PD | Nominal capacity | Reference pressure | Maximum pressure | Connections | Dimensions | Free spacefor cartridge replacement | Weight |
Standard | + | Standard | + | A | B | C | D |
l/s | cfm | l/s | cfm | bar(e) | psig | bar(e) | psig | in | mm | in | mm | in | mm | in | mm | in | kg | lbs |
12 | 10+ | 12 | 25 | 10 | 21 | 7 | 102 | 20 | 290 | 3/8 | 90 | 3.5 | 61 | 2.4 | 268 | 10.6 | 75 | 2.9 | 1.0 | 2.2 |
25 | 20+ | 25 | 53 | 20 | 42 | 7 | 102 | 20 | 290 | 1/2 | 90 | 3.5 | 61 | 2.4 | 268 | 10.6 | 75 | 2.9 | 1.1 | 2.4 |
45 | 35 | 45 | 95 | 35 | 74 | 7 | 102 | 20 | 290 | 1/2 | 90 | 3.5 | 61 | 2.4 | 323 | 12.7 | 75 | 2.9 | 1.3 | 2.9 |
215 | 170+ | 215 | 456 | 170 | 360 | 7 | 102 | 20 | 290 | 1-1/12 | 140 | 5.5 | 105 | 4.1 | 603 | 23.7 | 100 | 3.9 | 4.5 | 9.9 |
970F | 850+F | 970 | 2055 | 850 | 1801 | 7 | 102 | 16 | 232 | DN100 | 510 | 20.1 | 230 | 9.1 | 1360 | 53.5 | 1500 | 59.1 | 141 | 310.9 |
Product application
1.Hotels,
2.Garment Shops,
3.Building Material Shops,
4.Manufacturing Plant,
5.Machinery Repair Shops,
6.Food & Beverage Factory,
7.Farms, Restaurant,
8.Home Use,
9.Retail,
10.Food Shop,
11.Printing Shops,
12.Construction works ,
13.Energy & Mining,
14.Food & Beverage Shops,
15.Advertising Company
