Product Details
Particulate (After-Filter) Filters A particulate filter, also known asan after-filter, is usually located just after the desiccant airdryer to remove harmful liquid oil, water condensate, pipe scale,dirt and rust from your compressed air system. This helps preventscontaminants & corrosive damage to compressed air equipment andfinished products. If the particulate filter gets soiled morefrequently than what is typical for your environment, it may betime to replace the desiccant. Our Particulate Filter Replacementscome with a manufacture's warranty that matches or exceeds theoriginal OEM warranty. Original equipmentmanufacturer (OEM) names are the trademarks of each manufacturer.On products marked "replacement," OEM names and part numbers are for reference only.
TEST STANDARD:
Our filter elements are tested according to ISO 2943
Compatibility with suction fluids ISO 3968
Flow characteristics ISO/DIS 3724
Flow fatigue characteristics ISO/DIS 4572
Filter performance test (Multi-pass test) ISO 2942
Proof of integrity and quality (Bubble point test) ISO 3723
Verifiion of the end cap stress ISO 2941
Collapse / burst pressure verifiion
Product features
1.We use imported depthype filter material,tapered pore structure,gradient filter,can intercept granule furthest, to extend the service life
.2.We use hightech support materials.Hightech support materials can not only play the role of support filter, material and avoiding compressive deformation,but also protect the materials from being damaged during processing.
3.We also use the special spiral wrapping belts,so thar filter layers can be connected firmly.Stationary pleated distance ensures the uniform flow when fluid penetrating the filter layer.Not only improving pressure drop,but also extending service life.
Product parameters
Grade | Filtration rating | Oil content |
DD | 1µ | 1ppm |
DDP | 1µ | dust removal |
PD | 0.01µ | 0.01ppm |
QD | 0.01µ | 0.003ppm (activated carbon) |
Place of Origin: |
Henan, China |
Brand Name: |
LVDA |
Type: |
Air Filter,precision filter element |
Application: |
Atlas Copco Air Compressor |
Certificate: |
ISO9001:2015 |
Material: |
fiberglass imported from HV&Ahlstrom company.wire mesh /Stainless steel |
Pressure: |
High Pressure |
Filtration Efficiency: |
0.9999 |
Life cycle: |
> 6000 hours |
Filtration Precision: |
1 Micron |
Dimension(L*W*H): |
26.8*12.8*18.9cm |
Working Pressure: |
14 bar |
Description: |
Coalescent Filter 1/2' |
Air volume : |
2400(l/min) |
Maximum Oil Carryover : |
0.1 ppm Oil Removal |
FILTER SIZE
DD/PD | Nominal capacity | Reference
pressure | Maximum
pressure | Connections | Dimensions | Free space
for cartridge
replacement | Weight |
Standard | + | Standard | + | A | B | C | D |
l/s | cfm | l/s | cfm | bar(e) | psig | bar(e) | psig | in | mm | in | mm | in | mm | in | mm | in | kg | lbs |
45 | 35 | 45 | 95 | 35 | 74 | 7 | 102 | 20 | 290 | 1/2 | 90 | 3.5 | 61 | 2.4 | 323 | 12.7 | 75 | 2.9 | 1.3 | 2.9 |
215 | 170+ | 215 | 456 | 170 | 360 | 7 | 102 | 20 | 290 | 1-1/12 | 140 | 5.5 | 105 | 4.1 | 603 | 23.7 | 100 | 3.9 | 4.5 | 9.9 |
970F | 850+F | 970 | 2055 | 850 | 1801 | 7 | 102 | 16 | 232 | DN100 | 510 | 20.1 | 230 | 9.1 | 1360 | 53.5 | 1500 | 59.1 | 141.0 | 310.9 |
Product application
1.Power plant
2.Steel mill
3.Subway engineering
4.Chemical factory
5.Ship
6.Paper mill
